| 1 |
80A0B3347
|
WHEEL, REAR, B4
|
1 |
• |
|
€
1343.65
|
|
|
| 2 |
8000B5930
|
CHAIN LINK
|
1 |
• |
1 |
€
15.80
|
|
|
| 3 |
8000B3195
|
VALVE, WHEEL
|
1 |
• |
|
€
7.05
|
|
|
| 4 |
8000C4104
|
REAR HUB
|
1 |
|
|
€
660.00
|
|
|
| 5 |
800084909
|
GROMMET
|
1 |
• |
|
€
16.25
|
|
|
| 6 |
8000B7316
|
SPACER, REAR WHEEL HUB
|
1 |
|
|
€
0.00
|
|
|
| 7 |
8000B3198
|
HUB, REAR WHEEL, INNER SIDE
|
1 |
• |
|
€
839.75
|
|
|
| 8 |
80A084901
|
PIN
|
1 |
• |
|
€
8.30
|
|
|
| 9 |
800084890
|
FLANGE, REAR WHEEL HUB, INNER SIDE
|
1 |
• |
|
€
105.10
|
|
|
| 10 |
80A084902
|
SCREW, FLANGE PIN
|
1 |
• |
|
€
6.15
|
|
|
| 11 |
8A00B1654
|
DISK, REAR BRAKE
|
1 |
• |
|
€
0.00
|
|
|
| 12 |
8000B2767
|
SCREW, DISK BRAKE
|
1 |
|
|
€
5.45
|
|
|
| 13 |
800084891
|
NUT, M7
|
1 |
• |
|
€
9.80
|
|
|
| 14 |
8A00B0976
|
SUPPORT, REAR BRAKE CALIPER
|
1 |
• |
|
€
0.00
|
|
|
| 15 |
800086702
|
RUBBER RING, 3325 D82,22X2,62 (NBR SHORE
|
1 |
• |
|
€
1.70
|
|
|
| 16 |
800084893
|
WASHER, D81XD93XE0,7
|
1 |
• |
|
€
4.55
|
|
|
| 17 |
800084913
|
CIRCLIP, F80
|
1 |
• |
|
€
6.35
|
|
|
| 18 |
800084904
|
SPECIAL NUT, REAR WHEEL AXLE, LEFT SIDE
|
1 |
• |
|
€
67.70
|
|
|
| 19 |
800084898
|
STEEL RING, REAR WHEEL, LEFT SIDE
|
1 |
• |
|
€
16.75
|
|
|
| 20 |
80A082753
|
CALIPER, WITH PADS, REAR SIDE
|
1 |
• |
|
€
183.65
|
|
|
| 21 |
800082748
|
REAR BRAKE PADS
|
1 |
• |
|
€
64.80
|
|
|
| 22 |
800082746
|
PAD CHECK SPRING
|
1 |
• |
|
€
7.50
|
|
|
| 23 |
800082743
|
BRAKE PADS PIN
|
1 |
• |
|
€
11.50
|
|
|
| 24 |
800089484
|
DRAIN VALVE
|
1 |
• |
|
€
10.35
|
|
|
| 25 |
800089491
|
DUST COVER
|
1 |
• |
|
€
2.95
|
|
|
| 26 |
8A00B2690
|
SCREW, TCEIF M8X20 RT
|
1 |
• |
|
€
0.00
|
|
|
| 27 |
8000C9449
|
FLANGE REAR WHEEL HUB
|
1 |
• |
|
€
295.00
|
|
|
| 28 |
8000C3430
|
SPACER
|
1 |
• |
|
€
59.05
|
|
|
| 29 |
8000B2712
|
NUT, M8X1,25X8,5 CH12
|
1 |
• |
|
€
1.40
|
|
|
| 30 |
8000B2151
|
CUSHION, REAR WHEEL HUB
|
1 |
• |
|
€
2.15
|
|
|
| 31 |
80A0A3248
|
SPECIAL SCREW, REAR WHEEL HUB
|
1 |
• |
|
€
7.05
|
|
|
| 32 |
800084894
|
WASHER, D48,5XD65XE0,5
|
1 |
• |
|
€
2.30
|
|
|
| 33 |
800084903
|
SPECIAL NUT, REAR WHEEL AXLE, RIGHT SIDE
|
1 |
• |
|
€
76.60
|
|
|
| 34 |
800084899
|
STEEL RING, REAR WHEEL, RIGHT SIDE
|
1 |
• |
|
€
9.90
|
|
|
| 35 |
8D00B7337
|
FINAL GEAR BOX KIT
|
1 |
|
|
€
192.30
|
|
|
| 36 |
800094030
|
CAP, CIRCLIP
|
1 |
• |
|
€
1.60
|
|
|
| 37 |
8000B3390
|
FLANGE, REAR WHEEL HUB
|
1 |
• |
|
€
127.80
|
|
|
| 38 |
8000B2967
|
SPEED SENSOR
|
1 |
• |
|
€
82.10
|
|
|
| 39 |
8B0090901
|
SPECIAL SCREW, M4X8
|
1 |
• |
|
€
2.65
|
|
|
| 40 |
8000B5929
|
CHAIN
|
1 |
• |
|
€
171.40
|
|
|
| 41 |
8D00B7330
|
SPROCKET TRANSMISSION, Z43
|
1 |
|
|
€
81.50
|
|
|
